Product Introduction
Pallet Shuttle Racking System
A storage system consisting of wireless shuttle cars and shuttle shelves. The model of self-designed, produced, and sold vehicles and shelves greatly improves the operational stability of the project and provides customers with comprehensive shuttle car after-sales operation and maintenance support.
Homework Process
Operators use remote controls or tablet terminals to issue commands;
The shuttle car travels back and forth in the shelf aisle, transporting pallets to designated locations;
After completing a tunnel task, the shuttle car is transferred to the next tunnel by a forklift to continue working;
The system can set the storage mode of FIFO or FILO as needed.
Technical Specifications
| Shelf classification | Shuttle shelves |
| Shelf load capacity |
500KG |
| Tray type |
Sichuan shaped, Tian shaped |
| Tray material |
wood, plastic, steel |
| Walking method |
walking on a straight track |
| Remote control method |
handheld remote control |
| Operating temperature |
-25 ℃~40 ℃ |
| Shelf height |
Forklift/8200mm, Stacker/25000mm |
| Shelf depth |
≥ 50 meters |
| Shelf load capacity |
500~1500kg/pallet |
| Shelf layer height | arbitrary/recommended layer height 1800mm |
| Column material selection |
80/90/100/120/140 mm |
| Upgrade options | stacker crane/mother and child vehicle/elevator/conveyor line |
High density storage
The shuttle car shelving system fully utilizes three-dimensional space and can achieve dense storage of dozens of pallets in depth. The warehouse utilization rate is 30%~80% higher than traditional shelving, especially suitable for areas with high land prices and tight space.
Efficient operation
The shuttle car runs at high speed on the shelf track, without the need for forklifts to repeatedly enter the aisle, significantly improving the efficiency of inbound and outbound operations. Multiple shuttle buses can operate simultaneously, supporting parallel processing of multiple tasks, greatly improving warehouse throughput capacity.
Flexible Expansion
The system can be gradually expanded according to the needs of the enterprise, increasing the number of shuttle buses or upgrading to a fully automated system, with investment in stages and high cost-effectiveness.
Safe and reliable
The shuttle adopts advanced electronic control and collision avoidance systems, which ensure stable operation, precise positioning, and reduce safety hazards caused by human operation. The entire process of goods storage and retrieval does not require personnel to enter the aisle, significantly improving safety.
Intelligent management
Real time monitoring of shuttle status, inventory location, and job progress through WMS and WCS systems, supporting automatic scheduling and intelligent path planning, helping enterprises achieve refined and visual management.
Homework Process
Operators use remote controls or tablet terminals to issue commands;
The shuttle car travels back and forth in the shelf aisle, transporting pallets to designated locations;
After completing a tunnel task, the shuttle car is transferred to the next tunnel by a forklift to continue working;
The system can set the storage mode of FIFO or FILO as needed.
Core Advantages
High space utilization
Vertical space development with storage density 3-5 times higher than traditional flat storage.
Efficiency improvement in homework
24-hour uninterrupted operation, with 5-10 times higher efficiency in inbound and outbound than manual labor, and an error rate close to zero.
Cost optimization
Reduce labor demand (by more than 50%), lower land occupation costs, and minimize loss of goods.
Intelligent control
Real time monitoring of inventory status, supporting batch traceability, first in first out (FIFO) and other management rules, data can be integrated with ERP and other systems.
Case Studies
